High Voltage IGBT with Diode(Short Circuit SOA Capability)
- Series: -
- Brand: IXYS
- DateCode: 06+
- Package / Case: DIP8
- Packaging: Tube
- Part Status: Obsolete
- Driven Configuration: Low-Side
- Channel Type: Independent
- Number of Drivers: 2
- Gate Type: IGBT, N-Channel, P-Channel MOSFET
- Voltage - Supply: 4.5 V ~ 30 V
- Logic Voltage - VIL, VIH: 0.8V, 3V
- Current - Peak Output (Source, Sink): 2A, 2A
- Input Type: Non-Inverting
- Rise / Fall Time (Typ): 7.5ns, 6.5ns
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Through Hole
- Supplier Device Package: 8-PDIP
