HIGH SPEED-10 MBit/s LOGIC GATE OPTOCOUPLERS
All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
The parameters and performance indicators of this product are sourced from the internet. In case of discrepancies, please refer to the manufacturer's technical specifications!！
| QUANTITY | UNIT PRICE | PLUS UNIT PRICE | TOTAL PRICE |
|---|---|---|---|
| ≥1: | US $1.43220 | US $1.28898 | US $1.28898 |
| ≥5: | US $0.95480 | US $0.85932 | US $4.29660 |
| ≥10: | US $0.85932 | US $0.77339 | US $7.73390 |
| ≥20: | US $0.83545 | US $0.75191 | US $15.03820 |
| ≥50: | US $0.81158 | US $0.73042 | US $36.52100 |
| ≥100: | US $0.78771 | US $0.70894 | US $70.89400 |
| ≥200: | US $0.76384 | US $0.68746 | US $137.49200 |
| ≥500: | US $0.75429 | US $0.67886 | US $339.43000 |
| ≥1000: | US $0.73997 | US $0.66597 | US $665.97000 |
Substitute (equivalent) Product
| Product Name | Description |
|---|---|
| ACPL-223-00REHL | Dual Channel 10MBd, High Speed Optocoupler with open collector outputs, suitable for switching power supply applications. |
| HCPL-2231 | Similar to HCPL-2231-000E with opto-isolated open-collector outputs designed for high-speed digital interfacing. |
| HCPL-0600 | Single Channel 10MBd, High-Speed Transistor Optocoupler in an 8-pin DIP package, offering low input current and propagation delay. |
| 6N137 | High-Speed Optocoupler in an 8-DIP package providing 10MBd data rates, ideal for low power logic interfaces. |
| SFH618A | High-Speed Optocoupler with a transistor output,usually used in digital logic inputs and microprocessor systems. |
Product Usage
The HCPL-2231-000E is an optocoupler (also known as an optoisolator), specifically a high-speed, low input current logic gate optocoupler. It is typically used in circuits where electrical isolation and high-speed signal transmission are required. Some common applications include:
Digital Signal Isolation: The HCPL-2231-000E is used to transmit digital signals between different parts of a system that need to be electrically isolated from each other. This is important in systems where different subsystems operate at different voltage levels or need to be protected from high voltage spikes.
Microcontroller Interface: The optocoupler can interface microcontrollers with peripherals that operate at different voltages, providing isolation and protecting the microcontroller from potential faults.
Switch Mode Power Supplies (SMPS): In SMPS, the HCPL-2231-000E can be used to isolate the feedback control loop from the high voltage side to the low voltage control side.
Data Communication: It can be used in communication interfaces to provide galvanic isolation, ensuring that noise or spikes in one part of the system do not corrupt data transmission.
Motor Control Systems: It can be used to isolate control signals in motor driver circuits, protecting the low-voltage control circuit from high-voltage motor circuits.
Medical Equipment: In medical devices, isolation is crucial for patient safety. The HCPL-2231-000E can be used to ensure that control circuitry is electrically isolated from patient-contact areas.
Industrial Automation: Used to isolate sensors and actuators in an industrial environment, where potential differences and noise can interfere with control signals.
Telecommunication Equipment: Provides isolation in communication interfaces and protects circuitry from potential surges.
Key features of the HCPL-2231-000E include:
When designing circuits with the HCPL-2231-000E, engineers typically follow the manufacturer’s recommendations for input and output interfacing, taking into consideration the need for proper biasing and clamping circuitry to ensure reliable operation and signal integrity.
