-20V Single P-Channel HEXFET Power MOSFET in a Micro 3 package
Similar to IRLML6402 with Tape and Reel and Lead Free Packaging
All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
The parameters and performance indicators of this product are sourced from the internet. In case of discrepancies, please refer to the manufacturer's technical specifications!！
● Ultra Low On-Resistance
● P-Channel MOSFET
● SOT-23 Footprint
● Low Profile (<1.1mm)
● Available in Tape and Reel
● Fast Switching
Description
These P-Channel MOSFETs from International Rectifier utilize advanced processing techniques to achieve extremely low on-resistance per silicon area. This benefit,combined with the fast switching speed and ruggedized device design that HEXFET power MOSFETs are well known for, provides the designer with an extremely efficient and reliable device for use in battery and load management.
A thermally enhanced large pad leadframe has been incorporated into the standard sOT-23 package to produce a HEXFET Power MOSFET with the industry's smallest footprint. This package, dubbed the Micro3 TM, is ideal for applications where printed circuit board space is at a premium. The low profile (<1.1mm) of the Micro3 allows it to fit easily into extremely thin application environments such as portable electronics and PCMCIA cards. The thermal resistance and power dissipation are the best available.
| QUANTITY | UNIT PRICE | PLUS UNIT PRICE | TOTAL PRICE |
|---|---|---|---|
| ≥1: | US $0.23975 | US $0.21577 | US $0.21577 |
| ≥10: | US $0.17125 | US $0.15413 | US $1.54130 |
| ≥50: | US $0.13700 | US $0.12330 | US $6.16500 |
| ≥100: | US $0.12330 | US $0.11097 | US $11.09700 |
| ≥150: | US $0.11645 | US $0.10480 | US $15.72000 |
| ≥200: | US $0.11302 | US $0.10172 | US $20.34400 |
| ≥500: | US $0.11166 | US $0.10049 | US $50.24500 |
| ≥1000: | US $0.11028 | US $0.09925 | US $99.25000 |
| ≥3000: | US $0.10960 | US $0.09864 | US $295.92000 |
Substitute (equivalent) Product
| Product Name | Description |
|---|---|
| IRLML6344TRPBF | N-Channel Logic Level MOSFET, 30V, 3.8A, SOT-23 Package |
| IRLML6401TRPBF | N-Channel Logic Level MOSFET, 30V, 4.7A, SOT-23 Package |
| FDS6680 | N-Channel Logic Level MOSFET, 30V, 4.5A, SOT-23 Package |
| STB55NF06L | N-Channel Logic Level MOSFET, 60V, 5.5A, SOT-23 Package |
Product Usage
The IRLML6402TRPBF is a logic-level N-channel MOSFET (Metal-Oxide-Semiconductor Field-Effect Transistor) that is commonly used in various circuits due to its low on-state resistance (Rds(on)) and ability to handle relatively high currents for its size. Here are some typical applications and circuits where you might find the IRLML6402TRPBF:
Power Management Circuits:
Motor Control:
Switching Applications:
Signal Conditioning:
Power Supplies:
Audio Amplifiers:
LED Drivers:
Data Communication:
Automotive Applications:
Consumer Electronics:
The IRLML6402TRPBF is particularly well-suited for applications requiring low power consumption and high efficiency due to its low Rds(on) and small form factor (SOT-23 package). Its logic-level gate drive capability makes it easy to interface with microcontrollers and other digital logic circuits.
