Description
LM2576/LM2576HV Series SIMPLE SWITCHER® 3A Step-Down Voltage Regulator
Package: TO-263
No of Pins: 5
Qty per Container: 500/Reel
All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
The parameters and performance indicators of this product are sourced from the internet. In case of discrepancies, please refer to the manufacturer's technical specifications!！
Preview of the first 3 pages of the data sheet
| QUANTITY | UNIT PRICE | PLUS UNIT PRICE | TOTAL PRICE |
|---|---|---|---|
| ≥1: | US $1.30944 | US $1.17850 | US $1.17850 |
| ≥5: | US $0.87296 | US $0.78566 | US $3.92830 |
| ≥10: | US $0.78566 | US $0.70709 | US $7.07090 |
| ≥20: | US $0.76384 | US $0.68746 | US $13.74920 |
| ≥50: | US $0.74202 | US $0.66782 | US $33.39100 |
| ≥100: | US $0.72019 | US $0.64817 | US $64.81700 |
| ≥200: | US $0.69837 | US $0.62853 | US $125.70600 |
| ≥500: | US $0.68964 | US $0.62068 | US $310.34000 |
| ≥1000: | US $0.67654 | US $0.60889 | US $608.89000 |
Substitute (equivalent) Product
| Product Name | Description |
|---|---|
| LT1073-8.1 | 8.1V Micropower Step-Down Switching Regulator |
| NCV7914P50T3G | 50V, 1.5A, High Efficiency Synchronous Buck Regulator |
| TPS54302DDCR | 42V, 2A, Synchronous Step-Down Converter |
| ISL85415 | 60V, 5A, Synchronous Step-Down DC/DC Converter |
| MCP1640-E/SN | 6V to 17V Input, 0.8V to 5.25V Output, 250mA Step-Down DC/DC Converter |
Product Usage
The LM2576HVT-ADJ/LF03 is a high-voltage, adjustable step-down (buck) switching regulator from Texas Instruments. It is designed to operate over a wide input voltage range and can be used in various applications where a stable, regulated output voltage is required from a higher input voltage. Here are some common circuits and applications that might use the LM2576HVT-ADJ/LF03:
Power Supply Circuits:
Industrial Applications:
Automotive Electronics:
Consumer Electronics:
Medical Devices:
Telecommunications:
Here is a basic example of a circuit using the LM2576HVT-ADJ/LF03:
Required+Vin (10V to 40V)
|
|--- [LM2576HVT-ADJ/LF03]
| |
| |--- C1 (Input Capacitor, e.g., 100uF, 50V)
| |
| |--- L1 (Inductor, e.g., 100uH)
| |
| |--- D1 (Schottky Diode, e.g., 1N5822)
| |
| |--- C2 (Output Capacitor, e.g., 100uF, 16V)
| |
| |--- R1 (Adjustment Resistor, e.g., 1kΩ)
| |
| |--- R2 (Feedback Resistor, e.g., 5.1kΩ)
| |
|--- GND
|
+Vout ( Adjustable Output Voltage )
This circuit can be adjusted to provide a wide range of output voltages depending on the values of R1 and R2. The LM2576HVT-ADJ/LF03 is particularly useful in applications where a robust, efficient, and reliable power supply is needed.
